前置

会演示springcache的使用方式
项目地址: https://gitee.com/xmaxm/test-code/blob/master/chaim-cache/chaim-spring-cache/chaim-spring-cache-ehcache/README.md

前置配置

本篇文章是基于上篇文章进行: spring cache (默认方式)

强调:

在追踪源码的时候发现, 是通过注入ehCacheCacheManager进行文件的初始化, 当然解析xml文件也是该地方开始. 也就有了MyEhCacheCacheConfiguration,java方法. 大致思路同源码一致, 只是对获取的数据进行拦截, 增加部分数据, 进行一遍赋值操作

源码部分
spring cache (默认方式) 一致, 只是实现缓存的方式不一样

关键类: org.springframework.cache.Cache
org.springframework.cache.interceptor.CacheInterceptor#invoke
org.springframework.boot.autoconfigure.cache.CacheAutoConfiguration
实现类: org.springframework.cache.ehcache.EhCacheCache

pom: jar

org.springframework.bootspring-boot-starter-cache
net.sf.ehcacheehcache
javax.cachecache-api

org.reflectionsreflections0.9.10

配置文件:

ehcache.xml

application.yml

spring:cache:# 程序启动时创建的缓存名称cache-names: chaim-name# 缓存类型 org.springframework.boot.autoconfigure.cache.CacheTypetype: ehcacheehcache:config: classpath:ehcache.xml

MyEhCacheCacheConfiguration.java

package com.chaim.spring.cache.ehcache.config;import net.sf.ehcache.CacheManager;
import net.sf.ehcache.config.CacheConfiguration;
import net.sf.ehcache.config.Configuration;
import org.reflections.Reflections;
import org.reflections.scanners.MethodAnnotationsScanner;
import org.reflections.util.ClasspathHelper;
import org.reflections.util.ConfigurationBuilder;
import org.springframework.boot.autoconfigure.cache.CacheProperties;
import org.springframework.cache.annotation.Cacheable;
import org.springframework.cache.ehcache.EhCacheManagerUtils;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Primary;
import org.springframework.core.io.Resource;
import org.springframework.stereotype.Component;import java.lang.reflect.Method;
import java.util.Arrays;
import java.util.HashSet;
import java.util.Map;
import java.util.Set;/*** @author Chaim* @date 2022/9/23 0:11*/
@Component
@Primary
public class MyEhCacheCacheConfiguration {/*** 固定 ehcache.xml 中 cache标签name值为: CACHE_NAME 就进行全局配置*/private static final String CACHE_NAME = "CUSTOMIZE_GLOBAL";/*** 要扫描注解的包路径*/private static final String PACKAGE_NAME = "com.chaim.spring.cache.ehcache.controller";/*** 重写 org.springframework.boot.autoconfigure.cache.EhCacheCacheConfiguration#ehCacheCacheManager* 实现: 多 cache 标签自动添加** @param cacheProperties* @return*/@BeanCacheManager ehCacheCacheManager(CacheProperties cacheProperties) {Resource location = cacheProperties.resolveConfigLocation(cacheProperties.getEhcache().getConfig());if (location != null) {// 源码： 从给定资源中解析 EhCache 配置，以供进一步使用Configuration configuration = EhCacheManagerUtils.parseConfiguration(location);// 对获取的 ehcache 资源进行重写Map cacheConfigurations = configuration.getCacheConfigurations();// 校验其是否是全局标签 (配置该标签, 就标记需要缓存的都是此一个文件进行加载)CacheConfiguration cacheConfiguration = cacheConfigurations.get(CACHE_NAME);if (cacheConfiguration != null) {// 获取指定路径下的 @Cacheable 的 value 值, 也就是需要进行创建的缓存文件名Set allCacheableValue = this.getAllCacheableValue();allCacheableValue.forEach(key -> {if (cacheConfigurations.get(key) == null) {// 对象克隆, 该处涉及深浅拷贝CacheConfiguration clone = cacheConfiguration.clone();// 修改缓存文件名为 @Cacheable 的 value 值clone.name(key);// 将需要的值 PUT 进入 CacheConfiguration, 对应的cache标签值除name其余不变cacheConfigurations.put(key, clone);}});// 移除全局配置配置文件, 避免创建该文件无效cacheConfigurations.remove(CACHE_NAME);}// 源码: 返回CacheManagerreturn new CacheManager(configuration);}return EhCacheManagerUtils.buildCacheManager();}/*** 获取指定路径下所有 Cacheable 的 value 值** @return Cacheable -> value*/private Set getAllCacheableValue() {Set set = new HashSet<>();// 要扫描的包ConfigurationBuilder configurationBuilder = new ConfigurationBuilder().addUrls(ClasspathHelper.forPackage(PACKAGE_NAME)).addScanners(new MethodAnnotationsScanner());Reflections ref = new Reflections(configurationBuilder);// 获取扫描到的标记注解的集合Set methodsAnnotatedWith = ref.getMethodsAnnotatedWith(Cacheable.class);for (Method method : methodsAnnotatedWith) {Cacheable cacheable = method.getAnnotation(Cacheable.class);String[] value = cacheable.value();set.addAll(Arrays.asList(value));}return set;}
}
