前言

一、shape 是什么？

控件的形状，我们可以通过该shape来定制widget 的形状，来达到自己想还要的形状效果

二、不同的形状

下面的例子以card来给一个card 设置不同的形状

1.BeveledRectangleBorder

矩形边框：
通过调节circular 圆角半径

    return Scaffold(backgroundColor: Colors.amber,appBar: AppBar(// Here we take the value from the MyHomePage object that was created by// the App.build method, and use it to set our appbar title.title: Text(widget.title),),body: const Center(child: Card(// 矩形边框 side 设置边框的颜色和厚度shape: BeveledRectangleBorder(borderRadius: BorderRadius.all(Radius.circular(15)),side: BorderSide(color: Colors.green, width: 1)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)));

2.Border

代码如下（示例）：
可以设置方向的边框颜色和厚度

shape: Border(top: BorderSide(color: Colors.red, width: 2),right: BorderSide(color: Colors.green, width: 5),bottom: BorderSide(color: Colors.indigo, width: 7),left: BorderSide(color: Colors.pink, width: 12)),

3.CircleBorder圆形

  Card(// 圆形shape:CircleBorder(side: BorderSide(color: Colors.red, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)

4.ContinuousRectangleBorder连续圆角

  Card(// 连续的圆角矩形shape: ContinuousRectangleBorder(borderRadius: BorderRadius.all(Radius.circular(15)),side: BorderSide(color: Colors.red, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)

5.StadiumBorder 体育场边界 ，药丸形状

          Card(// 药丸形状shape: StadiumBorder(side: BorderSide(color: Colors.redAccent, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)

6.OutlineInputBorder外边框可以定制圆角

        Card(// 外边框可以定制圆角shape: OutlineInputBorder(borderRadius: BorderRadius.all(Radius.circular(15)),borderSide: BorderSide(color: Colors.redAccent, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)

7.UnderlineInputBorder下划线

       Card(// 下划线shape: UnderlineInputBorder(borderRadius: BorderRadius.all(Radius.circular(15)),borderSide: BorderSide(color: Colors.redAccent, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)

总结

import 'package:flutter/material.dart';void main() {runApp(const MyApp());
}class MyApp extends StatelessWidget {const MyApp({super.key});// This widget is the root of your application.@overrideWidget build(BuildContext context) {return MaterialApp(title: 'Flutter Demo',theme: ThemeData(// This is the theme of your application.//// Try running your application with "flutter run". You'll see the// application has a blue toolbar. Then, without quitting the app, try// changing the primarySwatch below to Colors.green and then invoke// "hot reload" (press "r" in the console where you ran "flutter run",// or simply save your changes to "hot reload" in a Flutter IDE).// Notice that the counter didn't reset back to zero; the application// is not restarted.primarySwatch: Colors.blue,),home: const MyHomePage(title: 'Flutter Demo Home Page'),);}
}class MyHomePage extends StatefulWidget {const MyHomePage({super.key, required this.title});// This widget is the home page of your application. It is stateful, meaning// that it has a State object (defined below) that contains fields that affect// how it looks.// This class is the configuration for the state. It holds the values (in this// case the title) provided by the parent (in this case the App widget) and// used by the build method of the State. Fields in a Widget subclass are// always marked "final".final String title;@overrideState createState() => _MyHomePageState();
}class _MyHomePageState extends State {@overrideWidget build(BuildContext context) {return Scaffold(backgroundColor: Colors.amber,appBar: AppBar(// Here we take the value from the MyHomePage object that was created by// the App.build method, and use it to set our appbar title.title: Text(widget.title),),body: Center(child: Column(children: const [Card(// 矩形边框 side 设置边框的颜色和厚度shape: BeveledRectangleBorder(borderRadius: BorderRadius.all(Radius.circular(15)),side: BorderSide(color: Colors.green, width: 1)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),),Card(// 矩形边框 side 设置边框的颜色和厚度shape: Border(top: BorderSide(color: Colors.red, width: 2),right: BorderSide(color: Colors.green, width: 5),bottom: BorderSide(color: Colors.indigo, width: 7),left: BorderSide(color: Colors.pink, width: 12)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),),Card(// 圆形shape:CircleBorder(side: BorderSide(color: Colors.red, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),),Card(// 连续的圆角矩形shape: ContinuousRectangleBorder(borderRadius: BorderRadius.all(Radius.circular(15)),side: BorderSide(color: Colors.red, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),),Card(// 药丸形状shape: StadiumBorder(side: BorderSide(color: Colors.redAccent, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),),Card(// 外边框可以定制圆角shape: OutlineInputBorder(borderRadius: BorderRadius.all(Radius.circular(15)),borderSide: BorderSide(color: Colors.redAccent, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),),Card(// 下划线shape: UnderlineInputBorder(borderRadius: BorderRadius.all(Radius.circular(15)),borderSide: BorderSide(color: Colors.redAccent, width: 10)),child: ListTile(trailing: Icon(Icons.shield),leading: Icon(Icons.shield_sharp),),)],)));}
}
